Ethernet Interface SY Signal Surge Protective Device for POE 262695mm Compact Design

Place of Origin : Fujian, China

Brand Name : SY

Model Number : SY3159

Type : T1, T2

Rated Voltage : 48V

Max Discharge current : 20 A

Interface : Ethernet, RJ45 Cat6

Data rate : 10/100/1000Mb/s

Line voltage : 75V POE75V

Operating Voltage : POE 90V

Max surge discharge current : 5KA(8-20μs)

Protected pins : All pins

Mounting : Grounding clip & Grounding terminal

Shell material : ABS

Size : 26*26*95mm

Weight : 52g

MOQ : 5 pieces

Price : $6.70/pieces >=5 pieces

Contact Now

Lightning arrester / RJ45 surge protector/SPD SY3159

This RJ45 surge protective device are widely used to against the lightning in the electronic equipment introducing data system, such as modern, server, working station, Hub, etc.

POE surge protector SY3159 is one of RJ45 surge protector, with DPR to against the lightning.

1.Specifications Details

Type	SY3159
Connection	Ethernet RJ45 Cat6 with POE
Data rate	10/100/1000Mb/s
Line voltage	75V POE 75V
Max continuous operating voltage	POE 90V
Max surge discharge current	5KA (8 to 20 μ s)
Protected pins	All pins
Mounting	Grounding terminal & Grounding clip
Shell material	ABS
Dimensions	262695mm
Package inch	4026105mm
Weight	52g

2.Dimensions

3.Main feature:

--ABS material profile shell, attractive and durable, good shielding effect;

--RJ 45, convenient to use, reliable connection;

--Introducing multilayer protection circuit, selecting the latest high-speed surge protection device of quick response, low output residual voltage and super transmission performance.

4.Package

Surge protector x 1

Grounding terminal /Grounding clip x 1

Manuals/Instructions x 1

5.Certificates

CE certificate

Compliant to ROHS

Lead-free

6.Service

A. OEM

B. If there other requirements for surge protector, pls send your specs to us, thanks!

Welcome your inquiry, we will do our best to support you!
